SilverStone SX650-G V1.1 650W 80 Plus Gold Power Supply > Black

19 Items sold in last 3 days
81 People watching this product now!
Category:
Description

Description

Designed for 80 PLUS Gold level of efficiency to reduce wasted heat and save on electricity.

Built-in 92mm FDB fan has excellent airflow and low noise, perfect for quiet home or office use.

100% modular cable design for easy removal in a case with cable routed and tied down

SilverStone’s flexible flat cables have much greater flexibility to allow for tighter folding and management of cables.

Powerful single +12V rail design, perfect for future high-end component upgrades or overclocking.

.±3% regulation and low ripple & noise performance for high stability.

Model No.
SST-SX650-G
Max. DC Output
650W
Power density
819W per liter
Load Range
+3.3V +5V +12V +5VSB -12V
Max.(Amps)
22A 22A 54.2A 2.5A 0.3A
Peak (Amps)
/ / / / /
Min.(Amps)
0A 0A 0A 0A 0A
Range (%)
±3% ±3% ±3% ±5% ±10%
Line Reg.(%)
±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p)
50mV 50mV 120mV 50mV 120mV
Color
Black (Lead-Free Paint)
Combined +3.3V & +5V
110W
Combined +12V
650W
Input Voltage
90 ~ 264 Vrms
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC (PF>0.9 at full load)
Efficiency
87%~90%(20% to 100% loading)
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over current protection

Over power protection

Over voltage protection

Short circuit protection

Under voltage protection

Connectors
V1.0

1 x 24 / 20-Pin motherboard connector (300mm)

1 x 8 / 4-Pin EPS / ATX 12V connector (400mm)

2 x 8 / 6-Pin PCIE connector (400mm / 150mm)

2 x 8 / 6-Pin PCIE connector (550mm / 150mm)

6 x SATA connector (“300mm / 220mm / 100mm” x 2)

3 x 4-Pin Peripheral connector (300mm / 200mm / 200mm)

1 x 4-Pin Floppy connector (100mm)

V1.1

1 x 24 / 20-Pin motherboard connector (300mm)

*1 x 8-Pin EPS and 1 x 4-Pin + 4-Pin ATX 12V connector (400mm / 150mm)

2 x 8 / 6-Pin PCIE connector (400mm / 150mm)

2 x 8 / 6-Pin PCIE connector (550mm / 150mm)

6 x SATA connector (“300mm / 220mm / 100mm” x 2)

3 x 4-Pin Peripheral connector (300mm / 200mm / 200mm)

1 x 4-Pin Floppy connector (100mm)

Cooling System
Single 92mm FDB silent fan
Form factor
SFX
Noise Level
18 dBA minimum
Dimension
125 mm (W) x 63.5 mm (H) x 100 mm (D)
4.92″ (W) x 2.5″ (H) x 3.94″ (D)
Weight
1.36 kg
Certification
80 PLUS Gold
Other
GPU Support list
Compatible with ATX12V v2.4
