Description
Die Casted Aluminum-Magnesium Alloy Frame & Frontplate Heatsink
The Die Casted Aluminum-Magnesium Alloy Frame enveloping the sides of the PCB help to strengthen the structural stiffness of the shroud to create a strong, scratch resistant and high quality finish that elevates the aesthetic and strength of the graphics card. Overlaying the entire PCB, the die casted Frontplate Heatsink cools the VRM, Memory and Chokes resulting in superior heat dissipation for top-notch airflow and cooling performance.
Digital Power Design
SAPPHIRE NITRO+ & PULSE AMD Radeon™ RX 7900 Series are designed with digital power which provides accurate power control and excellent power efficiency
Ultra High Performance Conductive Polymer Aluminum Capacitor
The Ultra High Performance Conductive Polymer Aluminum Capacitor has a small PCB foot print but high volumetric capacitance that makes 20-phase power possible on the RX 7900 series graphics card. The capacitor offers stable capacitance at a high frequency and temperature with very low signal noise, ensuring the stability and reliability of the product.
High TG Copper PCB
The GPU is mounted on to the high-density 14 layer 2oz Copper and high TG PCB to match the rapid speed, high current and increased power requirement of the GPU and memory to guarantee high stability of the PCB during operation.
Tough Metal Backplate
The all-aluminum backplate provides additional rigidity that guarantees nothing bends and dust stays out. It also helps cool your card by increasing heat dissipation.
Dedicated VRM Cooling
Dedicated VRM cooling module to create optimal heat dissipation for peak airflow and cooling performance.
Angular Velocity Fan Blade
The Angular Velocity Fan Blade provides a double layer of downward air pressure which alongside the air pressure on the outer ring of the Axial fan, results in up to 44% more downward air pressure and up to 19% more airflow for a quieter and cooler operation when compared to the previous generations.
Optimized Composite Heatpipe
The composite heatpipes are fine-tuned for each individual cooling design with optimal heat flow, efficiently and evenly spreading out the heat to the entire cooling module.
Assistive System Fan Control
When the temperature of the GPU increases, the graphics card fans speed up accordingly. To further help with cooling and heat dissipation, the Assistive System Fan Control feature in SAPPHIRE’s TriXX software controls the speed of a system fan to automatically increase at the same time as the graphics card fans, this assists in expelling the heated air from the entire system faster.
OC BIOS
This BIOS has been engineered to the maximum TGP setting for maximized gaming performance
Fuse Protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe.
Specifications
|
| SKU |
S88-4E471-020SA |
| Specifications |
| P/N |
CA-1M3-00M1WN-00 |
| SERIES |
H Series |
| MODEL |
H200 TG RGB |
| CASE TYPE |
Middle Tower |
| DIMENSION (H X W X D) |
454 x 210 x 416mm (17.9 x 8.3 x 16.4 inch) |
| NET WEIGHT |
7.4 kg / 16.31 lbs |
| SIDE PANEL |
4mm Tempered Glass x1 (Left) |
| COLOR |
Exterior & Interior: Black |
| MATERIAL |
SPCC |
| COOLING SYSTEM |
Rear (exhaust): 120 x 120 x 25 mm fan (1000rpm, 16dBA) |
| DRIVE BAYS |
-ACCESSIBLE
-HIDDEN
2 x 3.5’’ or 3 x 2.5’’ |
| EXPANSION SLOTS |
7 |
| MOTHERBOARDS |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
| I/O PORT |
USB 3.0 x 2, HD Audio x 1, RGB Button x 1 |
| PSU |
Standard PS2 PSU (optional) |
| FAN SUPPORT |
Refer to the provided details |
| RADIATOR SUPPORT |
Refer to the provided details |
| CLEARANCE |
CPU cooler height limitation: 180mm
VGA length limitation: 320mm |
| GPU |
AMD Radeon™ RX 7900 XTX Graphics Card |
| 5nm GPU |
|
| AMD RDNA™ 3 Architecture |
|
| Engine Clock |
Boost Clock: Up to 2680 MHz
Game Clock: Up to 2510 MHz |
| Stream Processors |
6144 |
| Compute Units |
96 CU (with RT+AI Accelerators) |
| Infinity Cache |
96MB |
| Ray Accelerators |
96 |
| Memory Size/Bus |
24GB/384 bit GDDR6 |
| Memory Clock |
20 Gbps Effective |
| Displays |
Maximum 4 Displays |
| Resolution |
HDMI™: 7680×4320
DisplayPort 2.1: 7680×4320 |
| Interface |
PCI-Express 4.0 x16 |
| Output |
2x HDMI
2x DisplayPort |
| BIOS Support |
Dual UEFI |
| Game Index |
4K |
| Sapphire Features |
Refer to the provided details |
| AMD Features |
Refer to the provided details |
| Cooler Type |
3 Fans
Vapor-X Cooling |
| Form Factor |
3.5 slot, ATX
Dimension: 320(L)X 135.75(W)X 71.6 (H)mm |
| Power Consumption |
420W Total Board Power |
| OS |
Linux, Windows 10, and Windows 11. 64-bit operating system required |
| System Requirement |
Minimum 800 Watt Power Supply
3 x 8-pin Power Connector.
PCI Express based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB recommended. |
|
| Brand |
SAPPHIRE |
| Weight |
4.000000 |
| Form Factor |
ATX |
| Chipset manufacturer |
AMD |
| Memory Size |
24 GB |
| GPU |
RX 7900 XT |
