Description

The ASUS ROG Strix B850-I Gaming WiFi is a high-performance mini-ITX motherboard designed for gamers and enthusiasts seeking a compact yet powerful platform. Compatible with AMD’s latest Ryzen™ 9000, 8000, and 7000 series desktop processors, it offers a range of advanced features tailored to meet the demands of modern gaming and computing.

Processor Compatibility and Power Delivery

Built on the AMD AM5 socket, the ROG Strix B850-I Gaming WiFi supports the latest Ryzen™ processors, ensuring robust performance for gaming and multitasking. Its 10+2+1 power stage design, rated for up to 70A per stage, provides stable and efficient power delivery, facilitating effective overclocking and system stability.

Memory and Storage

The motherboard features dual-channel DDR5 support, accommodating up to 64GB of RAM with speeds reaching 8400+ MHz when overclocked. This configuration ensures rapid data access and smooth multitasking. For storage, it offers two M.2 slots compatible with PCIe 5.0 x4, enabling high-speed data transfer rates suitable for demanding applications and games.

Expansion and Connectivity

Equipped with a PCIe 5.0 x16 slot featuring Q-Release Slim technology, the ROG Strix B850-I Gaming WiFi supports the latest graphics cards, providing enhanced bandwidth for superior gaming performance. The inclusion of WiFi 7 ensures ultra-fast wireless connectivity, reducing latency and improving online gaming experiences. Additionally, the motherboard includes an Intel® 2.5Gb Ethernet port for stable wired network connections.

USB and Audio Features

The rear I/O panel boasts a variety of USB ports, including a USB 20Gbps Type-C® port and multiple USB 10Gbps Type-A ports, facilitating quick data transfers and compatibility with a wide range of peripherals. The integrated audio solution delivers high-quality sound, enhancing the immersive experience in games and media consumption.

Cooling and Design

Advanced cooling solutions are integrated to maintain optimal temperatures during intensive tasks, ensuring consistent performance and longevity of components. The motherboard’s sleek design, complemented by customizable RGB lighting, allows users to personalize their setups to reflect individual styles.

Intelligent Control Features

ASUS AI Advisor, AI Overclocking, and AI Networking II are incorporated to provide intelligent system optimization, simplifying performance tuning and network management for users. These features enable automated adjustments, ensuring systems operate at peak efficiency with minimal manual intervention.

Form Factor and Compatibility

As a mini-ITX motherboard, the ROG Strix B850-I Gaming WiFi is ideal for compact builds without compromising on performance. Its form factor makes it suitable for small form factor cases, offering flexibility in system design while maintaining high-end capabilities.

Conclusion

The ASUS ROG Strix B850-I Gaming WiFi motherboard combines cutting-edge technology with a compact design, making it an excellent choice for gamers and enthusiasts seeking a powerful and feature-rich platform for their next build. Its support for the latest AMD processors, high-speed memory, advanced connectivity options, and intelligent optimization features ensure a top-tier computing experience.

Specifications:

Edition	ASUS ROG STRIX B850-I Gaming Wi-Fi
Form Factor	Mini-ITX
CPU Socket	AM5
Chipset	AMD B850
RAM Memory Support	DDR5 CUDIMM, Dual (2) Channels, ECC/Non-ECC, Max Capacity 96GB
Memory Speeds	DDR5 – 8000(OC), 8200(OC), 8400(OC)
Audio	ROG SupremeFX 7.1 HD Audio ALC4080
Primary GPU Interface	PCIe 5.0 (x16)
NVIDIA SLI Support	N/A
AMD CrossFire Support	N/A
Integrated Graphics	Requires Processor Graphics or Discrete GPU
On-Board Graphics Connectors	HDMI 2.1, USB Type-C (DisplayPort)
Expansion Slots	1 x M.2 22-42/60/80 (PCIe Gen5 x4), 1 x M.2 22-80 (PCIe Gen5 x4), 1 x PCIe 5.0 x16
SATA Support	2 x SATA 6GB/s (SATA3), RAID 0, RAID 1
Internal I/O Ports	1 x 24-pin Power, 1 x 8-pin Power, 1 x 4-pin CPU Fan Connector, 1 x 4-pin CHA_FAN, 1 x 4-pin AIO Pump Connector, 1 x Addressable Gen 2 Header, 1 x CPU_OV jumper, 1 x Front Panel Audio Header, 1 x Front Panel Connector, 1 x Thermal Sensor Header, 1 x USB 2.0 Header, 1 x USB 3.2 Gen1, 1 x USB 3.2 Gen2
External Connectivity	3 x Audio I/O, 1 x HDMI 2.1, 1 x RJ-45, 2 x USB 2.0, 4 x USB 3.2 Gen2 Type-A, 1 x USB 3.2 Gen2 Type-C/DisplayPort/G-Sync, 1 x USB 3.2 Gen2x2 Type-C
Network & Communication	802.11be Wi-Fi 7, 2.5 Gigabit LAN (10/100/1000/2500)
Rear I/O Buttons	BIOS Flashback, Clear CMOS, FlexKey
Cooling	Passive Heatsinks
Board Dimensions	170 x 170 mm
Model Number	90MB1K30-M0EAY0
GTIN	4711387823620
